FL-1070-CW 1070 nm CW Fiber Laser

$1,000,000.00

Output power

Quantity

Description: Continuous wave fiber laser at 1070nm. Features compact design, long lifetime, low cost and easy operation, widely used in pumping, scientific research, industrial and medical applications.

Applications: pumping, scientific research, industrial and medical applications

Model #: FL-1070-CW

Model	FL-1070-CW
Wavelength (nm)¹	1070±2
Line Width (nm)	<2
Operating Mode	CW
Output Power (W)	1-200
Transverse Mode	TEM00 @1-20W, Multimode @>20W
Power Stability (rms, 4 hours ±3°C)	<3%, <2%, <1%
M²	<1.2 @1-20W, <1.5 @>20W
Fiber Connector²	FC/APC, Collimator optional
Fiber Length (m)³	1
Fiber Jacket	PVC, Metal optional
Beam Diameter (mm)⁴	4±1 (Collimator output)
Polarization State	Random
Warm-Up Time (minutes)	<15
Operating Temperature (℃)	15-35
Cooled Method	Air cooled
Power Supply (VAC)	110/220VAC
Expected Lifetime (hours)	>10000

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Long lifetime
FDA registered
ISO and CE qualified
ROHS complied
Model # FL-1070-CW

Please request a quotation for a real price and lead time.

1070 nm

FL-1070-CW 1070 nm CW Fiber Laser
