MDL-E-417.5 417.5 nm Narrow Linewidth Diode Laser

Request a Quote

Description: It features a narrow spectral linewidth, stable wavelength, long lifetime and easy operation.

Applications: precision measurement, high resolution spectrum analysis

Model #: MDL-E-417.5

Model	MDL-E-417.5
Central Wavelength (nm)	417.5±0.5
Spectral Line Width (nm)	<0.06, <0.03
Operating Mode	CW
Output Power (mW)¹	1-50
Power Stability (rms, 4 hours ±3°C)	<3%, <2%, <1%
Frequency Shift (pm) (over ±2°C and 2hrs)	<20
Transverse Mode	Near TEM00
M²	<1.5
Beam Diameter at the Aperture (1/e², mm)	~1.3
Beam Divergence, Full Angle (mrad)	<1.5
Polarization Ratio	>50:1, (>100:1 optional) Horizontal±5 degree (Vertical optional)
Warm-Up Time (minutes)	<5
Cooled Method	Conduction
Beam Height from Base Plate (mm)	30
Operating Temperature (℃)	20-30
Power Supply (100-240VAC)	PSU-A-D
Expected Lifetime (hours)	>10000

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.
