236 nm LD Pumped All-Solid-Sate Passively Q-switched Pulsed Laser MPL-FN-236

Request a Quote

Description: All solid state passively laser is made features of ultra compact, long lifetime, cost-effectiveness and easy operating.

Applications: curing, micro-electronics, CD carving, laser medical treatment, scientific experiment

Model #: MPL-FN-236-XX-YY

Model	MPL-FN-236
Wavelength	236 nm
Average Power	1-3 mW
Repetition Rate	10 Hz-1 kHz
Power Stability	<5%, <3%
Warm-Up Time	< 5 min.
Operation Mode	Pulsed
Pulse Width	~1.4 ns
Single Pulse Energy	1-3 µJ
Peak Power	0.7-2.1 kW
Beam Diameter at the Aperture	~1.5 mm
Beam Divergence, Full Angle	~6.0 mrad
Transverse Mode	Near TEM00
M2	<2.0
Beam Height from Base Plate	27.4 mm
Operating Temperature	10-35 ℃
Power Supply (90 - 264 VAC)	PSU-SR
Expected Lifetime	>10000 (hours)

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.
