240 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser HPL-240-T

$1,000,000.00

Output power

Quantity

Description: All solid state Q-switched laser has the features of high peak power, high repetition rate, and short pulse duration.

Applications: marking, carving, measure, scientific research

Model #: HPL-240-T

Model	HPL-240-T
Wavelength	240 nm
Operation Mode	Pulsed (Q-switched)
Average Power	40 mW
Single Pulse Energy	4 µJ
Repetition Rate	1-10 kHz
Pulse Duration	<25 ns
Peak Power	0.16 kW
Power Stability	<5%, <3%
Beam Divergence, Full Angle	<2 mrad
Beam Diameter at the Aperture	<3 mm
M²	<1.5
Beam Height from Base Plate	73 mm
Cooling Method	Water cooled
Operating Temperature	15 ~ 35 ℃
Power Supply (220/110VAC)	PSU-AOM (4U)
Expected Lifetime	>10000 hours

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Please request a quotation for a real price and lead time.

240 nm
