OEM-IR-2130 2130 nm All-Solid-State Infrared Laser (OEM)

Request a Quote

Description: LD pumped all-solid-state 2130 nm infrared laser with high power, good beam quality and easy operation, in an OEM modular configuration.

Applications: material processing (especially plastics), pumping of mid-infrared laser sources, medical procedures such as precise tissue ablation, ophthalmic surgery and dentistry

Model #: OEM-IR-2130

Wavelength (nm)	2130±2
Operating Mode	CW
Output Power (W)	1-6
Beam Divergence, Full Angle (mrad)	<3
Beam Diameter at the Aperture (1/e2, mm)	<4
Power Stability (rms, 4 hours ± 3°C)	<5%, <3%
Beam Height from Base Plate (mm)	26.4
Warm-up Time (minutes)	<10
Cooled Method	Water cooled
Operating Temperature (°C)	10-30
Power Supply	PSU-MIR (3U)
Expected Lifetime (hours)	>10000

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Long lifetime
FDA registered
ISO and CE qualified
ROHS complied
Model # OEM-IR-2130

2130 nm
