577 nm LD Pumped All-Solid-Sate Yellow Laser MGL-F-577

$4,278.00

Quantity

Description: 577 nm LD Pumped All-Solid-State Yellow Laser MGL-F-577

Features: Diode laser pumped all-solid-state blue CW laser at 577 nm MGL-F-577, ultra-compact, long lifetime, cost-effective and user-friendly operation.

Applications: medical treatment, scientific research, optical instrumentation, laser display, laser lighting show tec.

Model	MGL-F-577	Wavelength	577 ± 2 nm
Average Power	>10, 20, 50, 80, ..., 2000 mW	Transverse Mode	Near TEM₀₀
Power Stability	<10%, 5%, 3%	Warm Up Time	< 10 min.
Operation Mode	LD pumped all solid state	Pointing Stability	<0.05 mrad
Beam Daimeter at the Aperture	~ 2.5 mm	M² Factor	<1.5
Beam Height from Base Plate	45 mm	Power Supply	PSU-H-FDA, or PSU-H-LED
Expected Lifetime	10000 (hours)	Warranty	12 months
Operating Temperature	10 ~ 35 ℃	Modulation	TTL on/off, 1Hz-1kHz

Please refer to Data Sheet for detailed specifications

Long life time
ISO and CE qualified
ROHS complied
Model # MGL-F-577

The list price is for Model #: MGL-F-577-30-5-1, 30 mW, 5% power stability, PSU-H-FDA power supply, no modulation. If you need a different model number, please feel free to ask a quotation.
