MIL-W-2128 2128 nm All-Solid-State Infrared Laser

Request a Quote

Description: LD pumped all-solid-state 2128 nm infrared laser featuring high power, good beam quality and easy operation.

Applications: material processing (especially plastics), pumping of mid-infrared laser sources, medical procedures such as precise tissue ablation, ophthalmic surgery and dentistry

Model #: MIL-W-2128

Wavelength (nm)	2128±5
Operating Mode	CW
Output Power (mW)	1-1500
Power Stability (rms, 4 hours ± 3°C)	<5%, <3%
Beam Divergence, Full Angle (mrad)	<6
Beam Diameter at the Aperture (1/e2, mm)	<4
Beam Height from Base Plate (mm)	98
Warm-up Time (minutes)	<10
Cooled Method	Air Cooled
Operating Temperature (°C)	15-35
Power Supply (100-240 VAC)	PSU-W-LED or PSU-W-FDA
Expected Lifetime (hours)	>10000

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Long lifetime
FDA registered
ISO and CE qualified
ROHS complied
Model # MIL-W-2128

2128 nm
