878.6 nm Fiber-Coupled Diode Laser System FC-W-878.6

$1,000,000.00

Output power

Quantity

Description: The FC-W-878.6 series (Fiber Coupling Laser System) integrates laser diode, fiber coupling optics, laser power supply, LD current and temperature control in ONE box. Its compact dimension and convenient functions make it very suitable for pumping, scientific research, industrial and medical applications.

Applications: pumping, scientific research, industrial and medical applications

Model #: FC-W-878.6

Wavelength	878.6
Operation Mode	CW
After Fiber Output Power	20-50 (FC-W-878.6) / 50-150 (FC-W-878.6H) / 200 (FC-W-878.6H-Water)
Power Stability	<2%, <1%, (<0.5% optional)
Red Pilot Light	Available on request
Fiber Core Diameter	400um, 0.22 NA
Fiber Connector	SMA905, FC/PC optional
Fiber Length	2 m
Fiber Jacket	Metal, PVC optional
LED Display	Diode current
Operating Temperature	10-40
Modulation Option	DC-1kHz, 1kHz-10kHz, 10kHz-30kHz, 30kHz-100kHz optional; TTL and Analog optional
Operating Voltage	100-240
Cooling Method	Air cooled / Water Cooled
Expected Lifetime	>10000

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Long lifetime
FDA registered
ISO and CE qualified
ROHS complied
Model # FC-W-878.6

Please request a quotation for a real price and lead time.
