MDL-N-1530 1530 nm High Power Infrared Diode Laser Module

$1,000,000.00

Output power

Quantity

Description: Diode infrared laser module at 1530 nm featuring ultra compact design, long lifetime and easy operating.

Applications: measurement, communication, spectrum analysis, etc.

Model #: MDL-N-1530

Wavelength (nm)	1530±10
Operating Mode	CW
Output Power (W)	1-3.5
Power Stability (rms, over 4 hours)	<0.5%, <1%, <2%
Transverse Mode	Multimode
M2 Factor	<20
Beam Divergence, Full Angle (mrad)	<3.0
Beam Diameter at the Aperture (1/e2, mm)	5-8
Warm-up Time (minutes)	<5
Beam Height from Base Plate (mm)	68.5
Operating Temperature (°C)	10-35
Power Supply (90-264 VAC)	PSU-H-LED/PSU-H-FDA
Modulation Option	TTL or Analog with 1 Hz-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz optional
Expected Lifetime (hours)	10000
Warranty	1 year

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Please request a quotation for a real price and lead time.
