MSL-III-783L 783 nm Single Longitudinal Mode Diode Laser

Request a Quote

Description: Single longitudinal mode infrared diode laser at 783nm, used in interferometry, bio-instrumentation, metrology, sensing, analytical instrumentation.

Applications: interferometry, bio-instrumentation, metrology, sensing, analytical instrumentation

Model #: MSL-III-783L

Model	MSL-III-783L
Central Wavelength (nm)	783±0.5
Operating Mode	CW
Output Power (mW)¹	1-80
Power Stability (rms, 4 hours ±3°C)	<2%, <1%, <0.5%
Transverse Mode	Near TEM00
Longitudinal Mode	Single
Spectral Line Width (MHz)	<100, (<50 optional)
Coherent Length (m)	>2
Noise of Amplitude (rms, 20Hz-20MHz)	<1%, <0.5%
M²	<1.5
Beam Diameter at the Aperture (1/e², mm)	~4.0
Beam Divergence, Full Angle (mrad)	<1.0
Polarization Ratio	>10:1
Warm-Up Time (minutes)	<5
Cooled Method	Conduction
Operating Temperature (℃)	10-35
Power Supply (100-240VAC)	PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM
Expected Lifetime (hours)	>10000

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Long lifetime
FDA registered
ISO and CE qualified
ROHS complied
Model # MSL-III-783L

783 nm

MSL-III-783L 783 nm Single Longitudinal Mode Diode Laser
