343 nm LD Pumped All-Solid-Sate Passively Q-switched Pulsed Laser MPL-N-343

Request a Quote

Description: CNI’s all solid state passively Q-switched UV laser features ultra compact, long lifetime, cost-effectiveness and easy operating.

Applications: UV curing, micro-electronics, CD carving, laser medical treatment, scientific experiment

Model #: MPL-N-343

Model	MPL-N-343
Wavelength	343 nm
Average Power	1-50 mW
Single Pulse Energy	0.1-7 µJ
Pulse Width	~7 ns
Peak Power	0.01-1 kW
Repetition Rate	4-8 kHz
Power Stability	<5%, <3%
Transverse Mode	Near TEM00
M2	<2.0
Beam Diameter at the Aperture	~1.0 mm
Polarization Ratio	>50:1, Horizontal (Vertical optional)
Warm-Up Time	< 5 min.
Beam Height from Base Plate	70 mm
Operating Temperature	10 ~ 35 ℃
Power Supply (90 - 264 VAC)	PSU-Q-FDA/PSU-Q-LED
Expected Lifetime	>10000 (hours)

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

343 nm
