351 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser AO-S-351

Request a Quote

Description: All solid state laser has the features of high peak power, high repetition rate and short pulse duration.

Applications: material processing, measure, scientific research

Model #: AO-S-351

Model	AO-S-351
Wavelength	351 nm
Operation Mode	Pulsed (Q-switched)
Average Power	1-30 mW
Single Pulse Energy	1-15 µJ
Pulse Width	6-10 ns @<10kHz
Peak Power	0.16-2.5 kW
Repetition Rate	1Hz-15kHz
M2	<1.5
Beam Divergence, Full Angle	<2 mrad
Beam Height from Base Plate	25 mm
Power Stability	<5%, <3%
Transverse Mode	TEM00
Beam Diameter at the Aperture	~1.0 mm
Polarization Ratio	>100:1, Horizontal (Vertical optional)
Warm-Up Time	< 10 min.
Operating Temperature	10 ~ 35 ℃
Power Supply (100 - 240 VAC)	PSU-AOM-DL
Expected Lifetime	>10000 (hours)

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.
