MSL-T-770 770 nm Single Longitudinal Mode Red Laser

Request a Quote

Description: All solid state single longitudinal mode laser is made features of ultra compact, which is widely used in quantum computing, cell sorting, laser cooling of potassium atoms, spectrum analysis, surface-enhanced Raman scattering, cold-atom physics.

Applications: quantum computing, cell sorting, laser cooling of potassium atoms, spectrum analysis, surface-enhanced Raman scattering, cold-atom physics

Model #: MSL-T-770

Model	MSL-T-770
Wavelength (nm)	770±1
Operating Mode	CW
Output Power (mW)¹	1-300
Power Stability (rms, 4 hours ±3°C)	<3%, <2%, <1%
Transverse Mode	TEM00
Longitudinal Mode	Single
Spectral Line Width (nm)	<0.000005
Coherent Length (m)	>30
M²	<1.2
Beam Diameter at the Aperture (1/e², mm)	<1.5
Beam Divergence, Full Angle (mrad)	<1.5
Polarization Ratio	>100:1, Vertical (Horizontal optional)
Warm-Up Time (minutes)	<5
Pointing Stability (µrad, over 2 hours after warm-up and ±3°C)	<50
Pointing Stability Over Temperature (µrad/°C)	<8
Beam Height from Base Plate (mm)	27.4
Operating Temperature (℃)	10-35
Power Supply (100-240VAC)	PSU-H-FDA
Expected Lifetime (hours)	>10000

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Long lifetime
FDA registered
ISO and CE qualified
ROHS complied
Model # MSL-T-770

770 nm
