MDL-NS-420 420 nm Nanosecond Pulsed Violet Diode Laser

$1,000,000.00

Output power

Quantity

Description: This series laser products with excellent material removal rate, are widely used in microelectronics, material processing, solar energy and medical equipment manufacturing, etc.

Applications: microelectronics, material processing, solar energy and medical equipment manufacturing

Model #: MDL-NS-420

Model	MDL-NS-420
Central wavelength (nm)	420±5
Operating mode	Pulsed
Peak power (mW)	1-100
Power stability (rms, 4 hours ±3°C)	<2%, <1%, <0.5%
Pulse width (FWHM)	10ns-10ms
Transverse mode	Near TEM00
M2	<1.2
Beam diameter at the aperture (1/e², mm)	~1.2
Beam divergence, full angle (mrad)	<1.0
Polarization ratio	>50:1, (>100:1 optional) Horizontal±5 degree (Vertical optional)
Rep. rate	DC-10MHz
Rise Time (ns)	<4
Fall Time (ns)	<3
Modulation Depth (extinction ratio)	>1000000:1
Warm-up time (minutes)	<5
Cooled method	Conduction
Beam height from base plate (mm)	19
Operating temperature	10-35
Operating voltage (VDC)	12V/3.34A
Expected lifetime (hours)	>10000

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.

Long lifetime
FDA registered
ISO and CE qualified
ROHS complied
Model # MDL-NS-420

Please request a quotation for a real price and lead time.

420 nm
