AO-K-289 289 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser

Request a Quote

Description: CNI’s all solid state Q-switched UV laser at 289 nm has the features of ultra compact and easy operating.

Applications: UV curing, micro-electronics, metrology, material processing, laser medical treatment, scientific experiment

Model #: AO-K-289

Model	AO-K-289
Wavelength	289 nm
Operation Mode	Pulsed (Q-switched)
Average Power	1-50 mW
Repetition Rate	10 kHz
Pulse Width	10 ± 2 ns
Single Pulse Energy	1~5 µJ
Peak Power	500 W @10kHz @50mW
Beam Diameter at the Aperture	Elliptical (1:2), beam spot 1.5×3 mm
Beam Divergence, Full Angle	<1 mrad
Power Stability	<5%, <3%
Beam Height from Base Plate	120 mm
Warm-Up Time	< 10 min.
Cooling Method	Air cooled
Power Supply	PSU-AOM (3U)
Expected Lifetime	10000 (hours)

Please refer to the Data Sheet for detailed specifications

If you need a different model number, please feel free to ask for a quotation.
