FC-W-1940H 1940 nm High Power Fiber Coupled Diode Laser System
$1,000,000.00
Description: High power fiber coupled diode laser system at 1940 nm integrating laser diode, fiber coupling optics, laser power supply, LD current and temperature control in one box. Water cooled version available for higher powers.
Applications: pumping, scientific research, industrial and medical applications
Model #: FC-W-1940H
| Model | FC-W-1940H / FC-W-1940H-Water |
| Wavelength (nm) | 1940±10 |
| Operating Mode | CW |
| After Fiber Output Power (W) | 15-20 (air cooled), 20-80 (water cooled, on request) |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, (<0.5% optional) |
| Red Pilot Light | Available on request |
| Fiber Core Diameter | 400 µm, 0.22 NA |
| Fiber Connector | SMA905, FC/PC optional |
| Fiber Length | 2 m |
| Fiber Jacket | Metal, PVC optional |
| LED Display | Diode current |
| Operating Temperature (°C) | 10-40 |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz, 30 kHz-100 kHz optional; TTL and Analog optional |
| Operating Voltage (VAC) | 100-240 |
| Cooled Method | Air cooled / Water cooled |
| Dimensions (mm) | 370 (L) ×406 (W) ×188 (H) (air cooled); water cooled on request |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FC-W-1940H
Please request a quotation for a real price and lead time.
