FL-1940-CW 1940 nm High Power All Fiber CW Laser
$1,000,000.00
Description: High power all fiber CW laser at 1940 nm with ultra compact design, long lifetime, low cost and easy operation. Available in three power versions (I: 1-10 W air cooled; II: 10-80 W air cooled; III: 80-100 W water cooled).
Applications: pump for medical surgery, plastic welding, cutting, non-metal materials processing, IR pumping source
Model #: FL-1940-CW
| Wavelength (nm) | 1940±1 |
| Operating Mode | CW |
| Output Power (W) | 1-100 (versions: I 1-10 W air; II 10-80 W air; III 80-100 W water) |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Spectral Linewidth (nm) | <2 |
| M² | <1.5 |
| Fiber Connector | Collimator |
| Fiber Length (m) | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm) | ~7 mm (Collimator output) |
| Polarization Ratio | Random |
| Cooled Method | Air cooled (≤30 W) / Water cooled (>30 W) |
| Warm-up Time (minutes) | <15 |
| Operating Temperature (°C) | 15-35 |
| Operating Voltage (VAC) | 110/220 VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1940-CW
Please request a quotation for a real price and lead time.
