263 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser AO-U-263
$1,000,000.00
Description: CNI’s all solid state AOM Q-switched laser at 263 nm has the features of high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measure, research
Model #: AO-U-263
| Model | AO-U-263 |
| Wavelength | 263 nm |
| Operation Mode | Pulsed (Q-switched) |
| Average Power | 200 mW @3kHz |
| Single Pulse Energy | >60 µJ |
| Pulse Width | <15 ns |
| Peak Power | ~4 kW |
| Repetition Rate | 1-10 kHz |
| Power Stability | <5%, <3% |
| Beam Divergence, Full Angle | <6×2 mrad |
| Beam Diameter at the Aperture | ~2×1 mm |
| Warm-Up Time | < 10 min. |
| Cooling Method | Air Cooled |
| Operating Temperature | 10 ~ 35 ℃ |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-U-263
Please request a quotation for a real price and lead time.
