266 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser EO-266W
$1,000,000.00
Description: All solid state EOM Q-switched laser at 266 nm has the features of high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measure, research
Model #: EO-266W
| Wavelength | 266±1 |
| Operation Mode | Electric-optic Q-switched |
| Average Power | 3 @50kHz |
| Single Pulse Energy | >60 @50kHz |
| Repetition Rate | 10-100kHz |
| Pulse Width | <5 |
| Power Stability | <2%, <1% |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle | <1.5 |
| Beam Diameter at the Aperture (1/e, mm) | ~2 |
| Polarization Ratio | >100:1 Vertical |
| Beam Height from Base Plate | 150 |
| Warm-Up Time | <10 |
| Cooling Method | Water cooled |
| Operating Temperature | 15-35 |
| Operating Voltage | 24V/31.1A |
| Expected Lifetime | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-266W
Please request a quotation for a real price and lead time.
