266 nm Picosecond All-Fiber Pulsed Laser FL-266-Pico
$1,000,000.00
Description: Picosecond all fiber pulsed laser at 266 nm features high output power stability, good beam profile, ultra compact, long lifetime, cost-effectiveness and easy operating.
Applications: scientific research, laser processing
Model #: FL-266-Pico
| Wavelength | 266±1 |
| Operation Mode | Pulsed |
| Average Power | 1-50 @1MHz |
| Power Stability | <5%, <3% |
| Pulse Width | 50-900 |
| M2 | <2 |
| Repetition Rate | 100kHz-20MHz |
| Polarization Ratio (dB) | >15 Horizontal (Vertical optional) |
| Warm-Up Time | <15 |
| Beam Height from Base Plate | 40 |
| Delivery Fiber Length | 60 |
| Cooling Method | Air cooled |
| Operating Temperature | 15-35 |
| Operating Voltage | 12V/11.5A |
| Expected Lifetime | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-266-Pico
Please request a quotation for a real price and lead time.
