491 nm LD Pumped All-Solid-State Single Frequency CW Blue Laser MBL-U-491-SF
$1,000,000.00
Description: All solid state single frequency blue laser features ultra compact, easy operating, high power and stability.
Applications: flow cytometry, spectrum analysis, microscopy, semiconductor inspection, cell sorting, optical instrument, physics experiment
Model #: MBL-U-491-SF
| Model | MBL-U-491-SF |
| Wavelength | 491 nm |
| Operation Mode | CW |
| Average Power | 1-400 mW |
| Power Stability | <3%, <2%, (<1% optional @ Water cooled) |
| Transverse Mode | TEM00 |
| M2 | ~3.0 |
| Beam Diameter at the Aperture | ~3.0 mm |
| Beam Divergence | <3.0 mrad |
| Polarization Ratio | >100:1 |
| Cooling Method | Air / Water cooled |
| Warm-Up Time | < 10 min. |
| Beam Height from Base Plate | 45 mm (Air) / 61.5 mm (Water) |
| Power Supply | PSU-SF |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MBL-U-491-SF
Please request a quotation for a real price and lead time.
