FL-618 618 nm Single Longitudinal Mode All Fiber Laser
$1,000,000.00
Description: All fiber single longitudinal mode laser at 618nm is made features of ultra compact, long lifetime, low cost and easy operating, which is widely used in measurement, spectrum analysis, interference, metrology, scientific research, etc.
Applications: measurement, spectrum analysis, interference, metrology, scientific research
Model #: FL-618
| Wavelength (nm) | 618±1 |
| Operating Mode | CW |
| Free Space Output Power (mW) | 1-50 |
| Fiber Coupled Output Power (mW) | 1-25 |
| Power Stability (rms, 4 hours) | <2%, <1% |
| Transverse Mode | TEM00 |
| Longitudinal Mode | SLM |
| Current Adjustment Range | 1-100% |
| Spectral Linewidth (MHz) | <100 |
| Temperature Tuning Range | >0.2 |
| PZT Tuning Range (GHz) | >5 |
| PZT Tuning Bandwidth (kHz) | >5 |
| Relative Intensity Noise | <0.3%, <0.1%, (<0.05% optional) |
| Frequency Shift (MHz) | <±200 |
| M² | <1.1 |
| Numerical Aperture | 0.12NA |
| Fiber Connector | FC/APC |
| Fiber Length (m) | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm) | ~1 @free space output |
| Pointing Stability (µrad) | <15 |
| Polarization Ratio (dB) | >15 Horizontal (Vertical optional) |
| Warm-up Time (minutes) | <30 |
| Cooled Method | Air cooled or Water cooled |
| Operating Temperature (℃) | 15-30 |
| Operating Voltage (VAC) | 110/220V |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-618
Please request a quotation for a real price and lead time.
