FC-W-638-525-450-1064-1470-55W Multi-Wavelength Fiber-Coupled Laser System
$1,000,000.00
Description: Multi-wavelength fiber-coupled laser system integrating red, green, blue and IR laser diodes with high output power and stability.
Applications: laser projection, laser shows, illumination, display, industrial processing
Model #: FC-W-638-525-450-1064-1470-55W
| Model | FC-W-638-525-450-1064-1470-55W |
| Wavelength (nm) | 638±10 / 525±10 / 450±10 / 1064 / 1470 |
| Output Power (W) @ after 200µm Fiber¹ | 0.4 / 3.9 / 4 / 22 / 25 |
| Operating Mode | CW |
| Cooled Method | Air cooled |
| Fiber Core Diameter (µm) | 200, 400, 0.22NA |
| Fiber Connector | SMA905, FC/PC optional |
| Fiber Length² | 1m |
| Fiber Jacket | PVC, Metal optional |
| Power Stability (rms, 4 hours±3℃) | <2%, <1% |
| Warm-Up Time (minutes) | <5 |
| Operating Temperature (℃) | 0-30 |
| Operating Voltage (VAC) | 100-240 |
| Modulation Option | DC-1kHz, 1kHz-10kHz, 10kHz-50kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FC-W-638-525-450-1064-1470-55W
Please request a quotation for a real price and lead time.
