EO-335 335 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser
$1,000,000.00
Description: All solid state EOM Q-switched laser at 335 nm has the features of high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measure, research
Model #: EO-335
| Model | EO-335 |
| Wavelength | 335 nm |
| Operation Mode | Pulsed (Q-switched) |
| Average Power | 1 W @10kHz |
| Single Pulse Energy | >100 µJ @10kHz |
| Repetition Rate | 10kHz |
| Pulse Width | <5 ns |
| Power Stability | <3%, <2%, <1% |
| Transverse Mode | TEM00 |
| M2 | <1.2 |
| Beam Divergence, Full Angle | <4 mrad |
| Beam Diameter at the Aperture | ~0.8 mm |
| Beam Height from Base Plate | 86 mm |
| Warm-Up Time | < 10 min. |
| Cooling Method | Air cooled |
| Operating Temperature | 10 ~ 35 ℃ |
| Operating Voltage | 24V/31.1A |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-335
Please request a quotation for a real price and lead time.
