HPL-330-P 330 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser
$1,000,000.00
Description: All solid state Q-switched laser at 330 nm has the features of high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measure, research
Model #: HPL-330-P
| Model | HPL-330-P |
| Wavelength | 330 nm |
| Operation Mode | Pulsed (Q-switched) |
| Average Power | 1-600 mW |
| Pulse Width | ~80 ns |
| Repetition Rate | 1 kHz |
| Single Pulse Energy | 1-600 µJ |
| Peak Power | 1-7.5 kW |
| Power Stability | <5%, <3% |
| Beam Divergence, Full Angle | <3 mrad |
| Beam Diameter at the Aperture | ~2 mm |
| Cooling Method | Water cooled |
| Beam Height from Base Plate | 60 mm |
| Warm-Up Time | < 10 min. |
| Power Supply (220VAC) | PSU-HPL |
| Operating Temperature | 15 ~ 30 ℃ |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # HPL-330-P
Please request a quotation for a real price and lead time.
