HPL-440-QM 440 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser
$1,000,000.00
Description: All solid state Q-switched blue laser at 440 nm has the features of high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measure, scientific research
Model #: HPL-440-QM
| Model | HPL-440-QM |
| Wavelength (nm) | 440±1 |
| Operating Mode | Electric-optic Q-switched |
| Average Power (W)¹ | 3-6 |
| Pulse Duration (ns) | ~100 @5kHz&6W |
| Rep. Rate² | 5kHz |
| Ave Power Stability (rms, 4 hours±3℃) | <5%, <3% |
| Beam Divergence, Full Angle (mrad) | <3.5 |
| Beam Diameter at the Aperture (1/e², mm) | <6 |
| Beam Height from Base Plate (mm) | 60 |
| Warm-Up Time (minutes) | <10 |
| Cooled Method | Water cooled |
| Operating Temperature (℃) | 15-35 |
| Power Supply (220-240AC) | PSU-HPL-Q & PSU-HPL-CW |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # HPL-440-QM
Please request a quotation for a real price and lead time.
