MDL-III-P-905 905 nm Infrared Diode Laser
$1,000,000.00
Description:
Applications: microelectronics, material processing, solar energy and medical equipment manufacturing
Model #: MDL-III-P-905
| Model | MDL-III-P-905 |
| Central wavelength (nm) | 905±10 |
| Operating mode | Modulation (Pulse) |
| Output power (mW) | >1, 2, 3,…, 25 |
| Transverse mode | Multimode |
| Dimensions of beam at the aperture (mm) | ~10×10 |
| Beam divergence, full angle (mrad) | <30 |
| Pulse duration (ns) | ~20 (@10kHz) |
| Peak power (W) | ~135 (@10kHz) |
| Rep. rate | 1~10 |
| Warm-up time (minutes) | <5 |
| Beam height from base plate (mm) | 24.8 |
| Operating temperature | 10~35 |
| Power supply | PSU-III-LED |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MDL-III-P-905
Please request a quotation for a real price and lead time.
