355 nm LD Pumped All-Solid-Sate Passively Q-switched Pulsed Laser MPL-Q-355
$1,000,000.00
Description: CNI’s all solid state passively Q-switched laser features ultra compact, long lifetime, cost-effectiveness and easy operating.
Applications: UV curing, micro-electronics, CD carving, laser medical treatment, scientific experiment
Model #: MPL-Q-355
| Model | MPL-Q-355 |
| Wavelength | 355 nm |
| Operation Mode | Pulsed (Q-switched) |
| Average Power | 1-150 mW |
| Single Pulse Energy | 0.1-15 µJ |
| Peak Power | 0.8-11.5 / 0.2-3.8 kW |
| Pulse Width | ~1.3 / ~4 ns |
| Repetition Rate | Int 3-5 / Ext 3-5 / QCW 9-12 kHz |
| Power Stability | <5%, <3% |
| Transverse Mode | Near TEM00 |
| M2 | <2 |
| Beam Diameter at the Aperture | ~1.0 mm |
| Beam Divergence, Full Angle | / |
| Polarization Ratio | >50:1, Horizontal (Vertical optional) |
| Warm-Up Time | < 5 min. |
| Beam Height from Base Plate | 35 mm |
| Operating Temperature | 10 ~ 35 ℃ |
| Power Supply (90 - 264 VAC) | PSU-Q-FDA/PSU-Q-LED |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MPL-Q-355
Please request a quotation for a real price and lead time.
