MDL-III-375 375 nm LD Pumped All-Solid-State CW UV Laser
Description: It features ultra compact design, long lifetime, cost-effectiveness and easy operation.
Applications: medical imaging, flow cytometry, DNA sequencing
Model #: MDL-III-375
| Model | MDL-III-375 |
| Central Wavelength (nm) | 375±5 |
| Operating Mode | CW |
| Output Power (mW)¹ | 1-150 / 150-400 |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1%, <0.5% |
| Transverse Mode | Multimode |
| Beam Diameter at the Aperture (1/e², mm) | <1.5×3.5 / ~2.0×4.0 |
| Beam Divergence, Full Angle (mrad) | ~2.3×0.2 / ~3.5×0.5 |
| Polarization Ratio | >50:1, (>100:1 optional) Horizontal±5 degree (Vertical optional) |
| Warm-Up Time (minutes) | <5 |
| Cooled Method | Conduction |
| Beam Height from Base Plate (mm) | 24.8 |
| Operating Temperature (℃) | 10-35 |
| Power Supply (100-240VAC) | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM |
| Modulation Option | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MDL-III-375
Please request a quotation for a real price and lead time.
