LiIO3 Nonlinear Crystal
LiIO3 Nonlinear Crystal
Lithium iodate single crystal is a kind of nonlinear crystal with early industrial application. It has large nonlinear coefficient, radiation damage resistance and wide light transmission range. It can be used as a medium for generating second harmonic and parametric oscillation in laser technology. It can be used as a second, triple frequency and mixing frequency for medium and low power lasers. It can also be used to manufacture narrow pulse and wideband ultrasonic transducers with broad application prospects in the aerospace, chamical, metallurgical and petroleum industries.
Key Features and Applications
- The mass production of LilO3 crystal
- Attractive discounts for OEM customers
- Different shapes (slabs, cylinders, Brewster ends) are available
- Standard open ring holders
- Re-coating and re-polishing service
- AR. BBAR and P-coatings according to customer's choice
- P-coatings optimized at pump wavelengths
- BBAR coatings for wavelength tuned Ti: Sapphire and other lasers
Specifications
| Parameter | Specifications |
|---|---|
| Flatness | λ/8 @633nm |
| Parallelism | ≤20 arcsec |
| Wavefront Distortion | λ/8 @633nm |
| Surface Quality | 10-5 |
| Perpendicularity | ≤5 arcmin |
| Angle tolerance° | ≤ 土 0.25° |
| Dimension tolerance | ±0.1mm |
| Clear Aperture | 90% of central area |
| Chamfer | ≤0.2mm x 45° |
Data Sheet: LiIO3 Nonlinear Crystal (PDF)
Dimensions, orientation and coatings are made to order - send us your specification for a quotation.
