AO-1342W 1342 nm High Power AOM Q-Switched Laser
$1,000,000.00
Description: High power AOM Q-switched solid-state laser at 1342 nm with driver integrated, featuring high peak power and short pulse duration.
Applications: material processing, marking, carving, measurement, scientific research
Model #: AO-1342W
| Wavelength (nm) | 1342±1 |
| Operating Mode | Actively Q-switched |
| Average Power (mW) | 600 @1 kHz, 6000 @30-90 kHz |
| Single Pulse Energy (µJ) | >600 @1 kHz, >150 @30 kHz, >100 @50 kHz |
| Repetition Rate | 1-30 kHz, 30-100 kHz |
| Pulse Duration (ns) | ~20 @1 kHz, ~55 @50 kHz |
| Peak Power (kW) | ~30 @1 kHz, ~2 @50 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1% |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle (mrad) | <4.5 |
| Beam Diameter at the Aperture (1/e2, mm) | ~2 |
| Polarization Ratio | >100:1 Horizontal |
| Beam Height from Base Plate (mm) | 59.5 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Water cooled |
| Operating Temperature (°C) | 10-35 |
| Operating Voltage (VDC) | 24 V/20.9 A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-1342W
Please request a quotation for a real price and lead time.
