266 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser AO-266W
$1,000,000.00
Description: All solid state AOM Q-switched laser at 266 nm has the features of high peak power, high repetition rate and short pulse duration.
Applications: radar, scientific research, precision research
Model #: AO-266W
| Wavelength | 266±1 |
| Operation Mode | Acousto-Optic Q-switched |
| Average Power | 500-700 @50kHz / 800-2000 @80kHz |
| Single Pulse Energy | >10 @50kHz / >15 @80kHz |
| Repetition Rate | 50-200kHz / 80-200kHz |
| Pulse Width | ~10 @50kHz / ~10 @80kHz |
| Peak Power | ~1 @50kHz / ~1.5 @80kHz |
| Power Stability | <3%, <2%, <1% |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle | <1.5 |
| Beam Diameter at the Aperture (1/e, mm) | ~1.0 |
| M2 | <1.2 |
| Polarization Ratio | >100:1 Horizontal |
| Warm-Up Time | <10 |
| Beam Height from Base Plate | 88.5 / 90 |
| Cooling Method | Water cooled |
| Operating Temperature | 10-35 |
| Operating Voltage | 24V/13A (AO-266W-I) / 30V/18.6A (AO-266W-II) |
| Expected Lifetime | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-266W
Please request a quotation for a real price and lead time.
