248 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser AO-DF-248
$1,000,000.00
Description: CNI’s all solid state Q-switched UV laser at 248 nm has the features of ultra compact and easy operating.
Applications: UV curing, micro-electronics, metrology and material processing, laser medical treatment, scientific experiment
Model #: AO-DF-248
| Model | AO-DF-248 |
| Wavelength | 248 nm |
| Operation Mode | Pulsed (Q-switched) |
| Average Power | 1-120 mW |
| Repetition Rate | 4-5 kHz |
| Pulse Width | ~10 ns |
| Single Pulse Energy | 1-24 µJ |
| Peak Power | 0.1-2.4 kW |
| Power Stability | <3%, <2% |
| Beam Divergence, Full Angle | <6×2 mrad |
| Beam Diameter at the Aperture | ~2×1 mm |
| Polarization Ratio | >100:1 |
| Warm Up Time | < 10 min. |
| Warranty | 1 year |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-DF-248
Please request a quotation for a real price and lead time.
