AO-K-280 280 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser
$1,000,000.00
Description: All solid state AOM Q-switched laser at 280 nm has the features of high peak power and short pulse duration.
Applications: scientific research, laser radar, laser marking
Model #: AO-K-280
| Model | AO-K-280 |
| Wavelength | 280±1 nm |
| Operation Mode | Pulsed (Q-switched) |
| Operating Mode | Acousto-Optic Q-switched |
| Average Power (mW) | 100 @5kHz |
| Single Pulse Energy (µJ) | >20 @5kHz |
| Rep. Rate | 5-10kHz |
| Pulse Duration (ns) | <10 @5kHz |
| Peak Power (kW) | ~4 @5kHz |
| Power Stability (rms, 4 hours ±3°C) | <5%, <3%, <2% |
| Beam Divergence, Full Angle (mrad) | <3.5 |
| Beam Diameter at the Aperture (1/e, mm) | ~1 |
| Polarization Ratio | >100:1 Horizontal |
| Beam Height from Base Plate (mm) | 116.5 |
| Warm-Up Time (minutes) | <10 |
| Cooled Method | Air cooled |
| Operating Temperature (°C) | 10-35 |
| Operating Voltage (VDC) | 24V/20.9A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-K-280
Please request a quotation for a real price and lead time.
