AO-K-289 289 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser
$1,000,000.00
Description: CNI’s all solid state Q-switched UV laser at 289 nm has the features of ultra compact and easy operating.
Applications: UV curing, micro-electronics, metrology, material processing, laser medical treatment, scientific experiment
Model #: AO-K-289
| Model | AO-K-289 |
| Wavelength | 289 nm |
| Operation Mode | Pulsed (Q-switched) |
| Average Power | 1-50 mW |
| Repetition Rate | 10 kHz |
| Pulse Width | 10 ± 2 ns |
| Single Pulse Energy | 1~5 µJ |
| Peak Power | 500 W @10kHz @50mW |
| Beam Diameter at the Aperture | Elliptical (1:2), beam spot 1.5×3 mm |
| Beam Divergence, Full Angle | <1 mrad |
| Power Stability | <5%, <3% |
| Beam Height from Base Plate | 120 mm |
| Warm-Up Time | < 10 min. |
| Cooling Method | Air cooled |
| Power Supply | PSU-AOM (3U) |
| Expected Lifetime | 10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-K-289
Please request a quotation for a real price and lead time.
