AO-Mini-E-1319 1319 nm Compact AOM Q-Switched Laser
$1,000,000.00
Description: Compact AOM Q-switched infrared laser at 1319 nm with driver integrated, high peak power and short pulse duration.
Applications: marking, carving, measurement, scientific research, nonlinear optics
Model #: AO-Mini-E-1319
| Wavelength (nm) | 1319±1 |
| Operating Mode | Actively Q-switched |
| Average Power (mW) | 140 @1 kHz, 500 @50 kHz |
| Single Pulse Energy (µJ) | 100 @1 kHz, 10 @50 kHz |
| Repetition Rate | 1-50 kHz |
| Pulse Duration (ns) | ~50 @1 kHz, ~850 @50 kHz |
| Peak Power (kW) | ~2 @1 kHz, ~0.01 @50 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <3%, <2%, <1% |
| Beam Divergence, Full Angle (mrad) | <2.0 |
| Beam Diameter at the Aperture (1/e2, mm) | ~2.0 |
| Beam Height from Base Plate (mm) | 80.2 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Air cooled |
| Operating Temperature (°C) | 10-35 |
| Operating Voltage (VDC) | 24 V/14.5 A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-Mini-E-1319
Please request a quotation for a real price and lead time.
