AO-S-1342 1342 nm AOM Q-Switched Solid-State Laser
$1,000,000.00
Description: All-solid-state actively Q-switched laser at 1342 nm featuring high peak power, high repetition rate and short pulse duration.
Applications: material processing, measurement, scientific research
Model #: AO-S-1342
| Wavelength (nm) | 1342±1 |
| Operating Mode | Actively Q-switched |
| Average Power (mW) | 1-1900 |
| Single Pulse Energy (µJ) | 1-150 (150 µJ @1 kHz; 100 µJ @10 kHz) |
| Pulse Duration (ns) | ~27 @1 kHz; ~35 @10 kHz |
| Peak Power (kW) | 0.1-5.5 |
| Repetition Rate | 1 Hz-100 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <3%, <2%, (<1% optional) |
| Transverse Mode | TEM00 |
| M2 | <1.5 |
| Beam Diameter at the Aperture (1/e2, mm) | ~1.2 |
| Beam Divergence, Full Angle (mrad) | <1.5 |
| Polarization Ratio | >100:1, Horizontal (Vertical optional) |
| Warm-up Time (minutes) | <10 |
| Beam Height from Base Plate (mm) | 25 |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-AOM-DL |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-S-1342
Please request a quotation for a real price and lead time.
