AO-Ti-360 360 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser
$1,000,000.00
Description: All solid state Q-switched violet blue laser at 360 nm has the features of high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measure, scientific research
Model #: AO-Ti-360
| Model | AO-Ti-360 |
| Wavelength | 360 nm |
| Operation Mode | Pulsed (Q-switched) |
| Repetition Rate | 1 / 30 / 50 kHz |
| Average Power | 1-700 mW (30kHz) / 1-800 mW (50kHz) |
| Pulse Width | ~25 ns (30kHz) / ~40 ns (50kHz) |
| Single Pulse Energy | 1-23 µJ (30kHz) / 1-16 µJ (50kHz) |
| Power Stability | <3%, <2%, (<1% optional) |
| Beam Diameter at the Aperture | ~2 mm |
| Beam Divergence, Full Angle | <2 mrad |
| Polarization Ratio | >100:1 Vertical |
| Beam Height from Base Plate | 107 mm |
| Warm-Up Time | < 10 min. |
| Cooling Method | Water cooled |
| Operating Temperature | 15 ~ 35 ℃ |
| Power Supply | 12V/26A |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-Ti-360
Please request a quotation for a real price and lead time.
