532/266 nm LD Pumped All-Solid-Sate Acousto-Optic Q-switched Pulsed Laser AO-U-532&266
$1,000,000.00
Description: All solid state AOM Q-switched laser at dual wavelengths 532 nm and 266 nm has the features of high peak power and short pulse duration.
Applications: laser radar, laser marking, scientific research
Model #: AO-U-532&266
| Wavelength | 532±1 / 266±1 |
| Operation Mode | Acousto-Optic Q-switched |
| Average Power | 2500 @3kHz / 3000 @5kHz (532); 300 @3kHz / 400 @5kHz (266) |
| Single Pulse Energy | >800 / >600 (532); >100 / >80 (266) |
| Repetition Rate | 1-10kHz |
| Pulse Width | ~13 / ~15 (532); ~10 / ~12 (266) |
| Peak Power | ~60 / ~40 (532); ~10 / ~6 (266) |
| Power Stability (rms, 4 hours) | <3%, <2%, <1% |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle | <3.5 |
| Beam Diameter at the Aperture (1/e, mm) | ~1.3 (532) / ~0.8 (266) |
| M2 | <1.2 |
| Polarization Ratio | >100:1 Vertical (532) / >100:1 Horizontal (266) |
| Beam Height from Base Plate | 116.3 |
| Warm-Up Time | <10 |
| Cooling Method | Air cooled |
| Operating Temperature | 10-35 |
| Operating Voltage | 12V/25A |
| Expected Lifetime | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-U-532&266
Please request a quotation for a real price and lead time.
