AO-V-1047 1047 nm LD Pumped All-Solid-State AOM Q-Switched Laser
$1,000,000.00
Description: All solid state AOM Q-switched laser at 1047 nm with high peak power and short pulse duration.
Applications: marking, carving, measurement, research, etc.
Model #: AO-V-1047
| Wavelength (nm) | 1047±1 |
| Operating Mode | Actively |
| Average Power (W) | 1-3 @3 kHz |
| Single Pulse Energy (µJ) | 1-2000 |
| Rep. Rate (kHz) | 1-10 |
| Pulse Duration (ns) | ~10 @3 kHz |
| Peak Power (kW) | 1-250 |
| Average Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Warm-up Time (minutes) | <10 |
| Beam Divergence, Full Angle (mrad) | <2 |
| Beam Diameter at the Aperture (1/e2, mm) | ~2.0 |
| Beam Height from Base Plate (mm) | 49 |
| Cooling Method | Air cooled |
| Operating Temperature (℃) | 10-35 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-V-1047
Please request a quotation for a real price and lead time.
