AO-V-1064A 1064 nm High Power LD Pumped All-Solid-State AOM Q-Switched Laser
$1,000,000.00
Description: All solid state AOM Q-switched laser at 1064 nm with high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measurement, research and so on
Model #: AO-V-1064A
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Average Power (W) | 10 @10 kHz / 10 @20 kHz / 20 @50 kHz / 20 @100 kHz |
| Single Pulse Energy (µJ) | >1000 @10 kHz / >500 @20 kHz / >400 @50 kHz / >200 @100 kHz |
| Rep. Rate | 1-10 kHz / 20-200 kHz |
| Pulse Duration (ns) | ~35 @10 kHz / ~12 @20 kHz / ~17 @50 kHz |
| Peak Power (kW) | ~28 @10 kHz / ~40 @20 kHz / ~23 @50 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1% |
| Beam Divergence, Full Angle (mrad) | <1.5 |
| Beam Diameter at the Aperture (mm) | ~6.0 |
| M2 | <1.2 |
| Polarization Ratio | >100:1 Horizontal |
| Pilot Light (optional) | ~5 mW @650 nm |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # AO-V-1064A
Please request a quotation for a real price and lead time.
