DPS-1064-LR 1064 nm High Energy Diode Pumped All-Solid-State Q-Switched Laser (Long Range)
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 1064 nm designed for long-range laser ranging applications.
Applications: laser ranging, LIDAR, scientific research
Model #: DPS-1064-LR
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (mJ) | 50 / 80 |
| Pulse Duration (ns) | <10 |
| Rep. Rate | 20 Hz |
| Energy Stability (std dev/mean) | <2%, <1%, <0.5% |
| Beam Divergence, Full Angle (mrad) | ≤0.5 |
| Beam Diameter (mm) | ~30 |
| Warm-up Time (minutes) | <15 |
| Beam Height from Base Plate (mm) | 31 |
| Ranging Accuracy (m) | ±2 |
| Laser Ranging Distance | Max ≥10 km / Min 150 m (50 mJ); Max ≥20 km / Min 150 m (80 mJ) |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | -40 to 60 |
| Operating Voltage (VDC) | 24 V/18.8 A |
| Expected Lifetime (pulses) | 5×10⁷ |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # DPS-1064-LR
Please request a quotation for a real price and lead time.
