DPS-1064-Neoma 1064 nm High Energy Diode Pumped All-Solid-State Q-Switched Laser
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 1064 nm with high single pulse energy, short pulse duration and high peak power.
Applications: LIBS, scientific research, laser induced breakdown spectroscopy, etc.
Model #: DPS-1064-Neoma
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (mJ) | 1-50 |
| Pulse Duration (ns) | <13 |
| Jitter (ns, Sdev) | <1 (Int.) |
| Rep. Rate | 1-100 Hz (adjustable) |
| Energy Stability (std dev/mean) | <3%, <2%, <1% |
| Beam Diameter (mm) | ~3.5×3.5 (square) |
| Beam Divergence, Full Angle (mrad) | ≤9 |
| Warm-up Time (minutes) | <15 |
| Beam Height from Base Plate (mm) | 45.5 |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | 15-35 |
| Operating Voltage (VDC) | 48 V/7.3 A |
| Expected Lifetime (pulses) | 10⁹ |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # DPS-1064-Neoma
Please request a quotation for a real price and lead time.
