DPS-1064-PIV 1064 nm High Energy Diode Pumped All-Solid-State Q-Switched Laser (PIV)
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 1064 nm designed for PIV applications with dual pulse capability.
Applications: PIV (Particle Image Velocimetry), scientific research
Model #: DPS-1064-PIV
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (mJ) | 100 @ single pulse |
| Pulse Duration (ns) | <10 |
| Rep. Rate | 10-20 Hz (adjustable) |
| Energy Stability (std dev/mean) | <2%, <1%, <0.5% |
| Beam Divergence, Full Angle (mrad) | ≤3 |
| Beam Diameter (mm) | ~5 |
| Warm-up Time (minutes) | <15 |
| Beam Height from Base Plate (mm) | 30.5 |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | -20 to 55 |
| Operating Voltage (VDC) | 24 V/25 A |
| Expected Lifetime (pulses) | 10⁹ |
| Delay Between Two Pulses (ns) | 0-50000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # DPS-1064-PIV
Please request a quotation for a real price and lead time.
