266 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser DPS-266-Neoma
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 266 nm has the features of high single pulse energy, short pulse duration and high peak power.
Applications: PIV, LIF, LIBS, ICP-MS scientific research, laser processing
Model #: DPS-266-Neoma
| Wavelength | 266±1 |
| Operation Mode | Electric-optic Q-switched |
| Single Pulse Energy | 1-3 |
| Pulse Width | <12 |
| Jitter | <1 (Int.) |
| Repetition Rate | 1-100Hz (adjustable) |
| Energy Stability | <5%, <3%, <2% |
| Beam Diameter | ~3.5×3.5 |
| Beam Divergence, Full Angle | ≤7 |
| Beam Height from Base Plate | 46 |
| Warm-Up Time | <15 |
| Cooling Method | Air cooled |
| Operating Temperature | 15-35 |
| Operating Voltage | 48V/7.3A |
| Expected Lifetime | 10⁹ |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # DPS-266-Neoma
Please request a quotation for a real price and lead time.
