266 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser DPS-266-Q
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 266 nm has the features of high single pulse energy, short pulse duration and high peak power.
Applications: LIBS, LIF, PIV, ICP-MS, LCD repair, scientific research, laser processing
Model #: DPS-266-Q
| Wavelength | 266±1 |
| Operation Mode | Electric-optic Q-switched |
| Single Pulse Energy | 1-2 / 2-5 |
| Pulse Width | <10 |
| Jitter | <1 (Int.) |
| Repetition Rate | 1-100Hz (adjustable) |
| Energy Stability | <5% |
| Beam Divergence, Full Angle | <3 |
| Beam Diameter | ~2 / ~2.5 |
| Warm-Up Time | <15 |
| Beam Height from Base Plate | 55 |
| Cooling Method | Water cooled |
| Operating Temperature | 15-30 |
| Power Supply (110 - 220 VAC) | PSU-DPS-Q |
| Expected Lifetime | 10⁹ |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # DPS-266-Q
Please request a quotation for a real price and lead time.
