DPS-280-R 280 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 280 nm has the features of high single pulse energy, short pulse duration and high peak power.
Applications: Lidar, Laser spectroscopy, Sensing and metrology
Model #: DPS-280-R
| Model | DPS-280-R |
| Wavelength | 280±1 nm |
| Operation Mode | Pulsed (Q-switched) |
| Operating Mode | Electric-optic Q-switched |
| Single Pulse Energy (µJ) | 1-500 |
| Pulse Duration (ns) | <10 |
| Jitter (ns, sdev) | <1 (Int.) |
| Rep. Rate | 1-100Hz (adjustable) |
| Energy Stability (std dev/mean) | <5% |
| Beam Divergence, Full Angle (mrad) | <25 |
| Beam Diameter (mm) | ~2×2 |
| Warm-Up Time (minutes) | <15 |
| Cooled Method | Air cooled or water cooled |
| Operating Temperature (°C) | 15-30 |
| Operating Voltage (VDC) | 48V/7.3A |
| Expected Lifetime (pulses) | 10⁹ |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # DPS-280-R
Please request a quotation for a real price and lead time.
