DPS-589-R 589 nm LD Pumped All-Solid-State Q-Switched Pulsed Laser
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 589nm has the features of high single pulse energy, short pulse duration, and high peak power, which is widely used in Lidar, Laser spectroscopy, Sensing and metrology, and so on.
Applications: Lidar, laser spectroscopy, sensing and metrology
Model #: DPS-589-R
| Wavelength (nm) | 589±1 |
| Operating Mode | Actively Q-switched |
| Single Pulse Energy (mJ) | 1-5 |
| Pulse Duration (ns) | <10 |
| Jitter (ns, sdev) | <1ns (Int.) |
| Repetition Rate | 1-100Hz (adjustable) |
| Energy Stability (std dev/mean) | <5%, <3% |
| Beam Divergence, Full Angle (mrad) | <25 |
| Beam Diameter (mm) | ~5×5 |
| Warm-up Time (minutes) | <15 |
| Cooling Method | Air cooled or water cooled |
| Operating Temperature (℃) | 15-30 |
| Operating Voltage (VDC) | 48V/7.3A |
| Expected Lifetime (pulses) | 10⁹ |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # DPS-589-R
Please request a quotation for a real price and lead time.
