EO-1064-G 1064 nm High Energy Diode Pumped All-Solid-State Q-Switched Laser
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 1064 nm with high single pulse energy, short pulse duration and high peak power.
Applications: high energy applications, scientific research
Model #: EO-1064-G
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Average Power (W) | 50 mW-4 W @5 kHz / 250 mW-7.5 W @25 kHz / 20 mW-5 W @2 kHz / 500 mW-10 W @50 kHz |
| Single Pulse Energy (mJ) | 10 µJ-0.8 mJ @5 kHz / 10 µJ-0.3 mJ @25 kHz / 10 µJ-2.5 mJ @2 kHz / 10 µJ-0.2 mJ @50 kHz |
| Pulse Duration (ns) | <8 @5 kHz / <15 @25 kHz / <15 @2 kHz / <8 @50 kHz |
| Rep. Rate | 1-25 kHz / 1-3 kHz / 1-100 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1% |
| M2 | <1.2 / <2 |
| Pointing Stability (μrad, std) | <20 |
| Beam Divergence, Full Angle (mrad) | <3 |
| Beam Diameter (mm) | ~1 |
| Beam Height from Base Plate (mm) | 80, 564 / 78 |
| Warm-up Time (minutes) | <15 |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | 15-30 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-1064-G
Please request a quotation for a real price and lead time.
