EO-1064-H 1064 nm High Energy Diode Pumped All-Solid-State Q-Switched Laser
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 1064 nm with high single pulse energy, short pulse duration and high peak power.
Applications: high energy applications, scientific research
Model #: EO-1064-H
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (mJ) | 0.75 @5 kHz / 0.75-1.5 @3 kHz |
| Pulse Duration (ns) | <7 @5 kHz / <10 @3 kHz |
| Rep. Rate | 1-10 kHz / 1-3 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1% |
| M2 | <1.5 / <2 |
| Pointing Stability Over Temperature (μrad/°C) | <20 |
| Beam Divergence, Full Angle (mrad) | <3 |
| Beam Diameter (mm) | ~1 |
| Beam Height from Base Plate (mm) | 76.5 / 85 |
| Warm-up Time (minutes) | <15 |
| Cooled Method | Conduction (EO-1064-H-I) / Air cooled (EO-1064-H-II) |
| Operating Temperature (℃) | -20 to 55 |
| Power Supply (24 VDC) | PSU-EO-H (24 V/13 A) |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-1064-H
Please request a quotation for a real price and lead time.
